Axle Mounting Bracket Bundle 3" Axle Tube

A bundle of 16 commonly used axle mounting brackets, designed for custom suspension applications. Short 90mm and tall 125mm configurations included.

(measure from axle center to bracket mounting hole)

This file is designed for the hands-on fabricator: just pick the bracket geometry that best fits your application, send the file directly to your local laser/plasma cutter (or cut it on your CNC table), and weld it straight onto your axle. Features a folded slot and tab gusset for alignment and strength. These brackets are available in multiple different size configurations to suit a wide range of applications.

What You Get: This digital download includes the production-ready files you need to get manufacturing immediately:

• DXF File: Clean, scaled, and ready for CNC laser, plasma, or waterjet cutting.

• STEP File: For viewing in 3D or dropping into your own CAD assemblies to test fitment before cutting.

• PDF File: For general size specifications and folding details

Bracket sizes included:

• Tall 125mm:

  • Axle Mount Bracket - Tall - 125mm - 12.75D - 2.0IN - 3IN AXLE - 0deg

  • Axle Mount Bracket - Tall - 125mm - 12.75D - 2.0IN - 3IN AXLE - 10deg

  • Axle Mount Bracket - Tall - 125mm - 12.75D - 2.0IN - 3IN AXLE - 15deg

  • Axle Mount Bracket - Tall - 125mm - 12.75D - 2.0IN - 3IN AXLE - 20deg

  • Axle Mount Bracket - Tall - 125mm - 14D - 1.25IN - 3IN AXLE - 0deg

  • Axle Mount Bracket - Tall - 125mm - 14D - 1.25IN - 3IN AXLE - 10deg

  • Axle Mount Bracket - Tall - 125mm - 14D - 1.25IN - 3IN AXLE - 15deg

  • Axle Mount Bracket - Tall - 125mm - 14D - 1.25IN - 3IN AXLE - 20deg

• Short 90mm:

  • Axle Mount Bracket - Short - 90mm - 12.75D - 2.0IN - 3IN AXLE - 0deg

  • Axle Mount Bracket - Short - 90mm - 12.75D - 2.0IN - 3IN AXLE - 10deg

  • Axle Mount Bracket - Short - 90mm - 12.75D - 2.0IN - 3IN AXLE - 15deg

  • Axle Mount Bracket - Short - 90mm - 12.75D - 2.0IN - 3IN AXLE - 20deg

  • Axle Mount Bracket - Short - 90mm - 14D - 1.25IN - 3IN AXLE - 0deg

  • Axle Mount Bracket - Short - 90mm - 14D - 1.25IN - 3IN AXLE - 10deg

  • Axle Mount Bracket - Short - 90mm - 14D - 1.25IN - 3IN AXLE - 15deg

  • Axle Mount Bracket - Short - 90mm - 14D - 1.25IN - 3IN AXLE - 20deg

Need more options? If you are building a complete setup and aren't sure exactly which geometries you need yet, check out our Tusker Designs Master Bracket Bundle on our store page to get our entire library of bracket variations for one highly discounted price!

Fabrication, Modification & Liability Policy All Tusker Designs file packages are supplied strictly as universal blueprints. They are intentionally designed to be modified, scaled, and adapted to your unique project requirements.

To the maximum extent permitted by law, Tusker Designs digital products are sold on an "as-is" basis for motorsport and off-road use only. Because Tusker Designs has no control over your physical fabrication process, material selection, cutting accuracy, welding quality, or adherence to local vehicle standards, we accept no liability for the final physical build. It is the buyer’s sole responsibility to safely modify, weld, and thoroughly pressure-test all finished components at their own risk.

NOTE: Axle Housing is for reference only and not included with this product.

NOTE: This is a digital product only, no physical items will be shipped.

NOTE: Product images are for display purposes only, images may not depict the exact proportions of your selected bracket.
